Configuration table between 3300V+ and 2910V
WAN IP
3300V+ 220.135.240.207
2910V
61.31.167.135
Suppose the number of PBX's Outside Line is 12345678. One Inside Line is connected to a
telephone with the extension 101. If you want to use PSTN from the extension, you must
firstly press 0, and then dial the phone number.
The ISDN-TE Port5 on the 3300V+ is connected to PBX's Inside Line with the number 102.
The number of another PSTN line is 87654321.
About VoIP basic settings please refer to VoIP Example 2 (Basic configuration and
registration for ISDN)
Start to dial by using telephones.
Phone 1 calls Phone 2---->Press extension 102. After getting through you will hear the dial
tone, then press the VoIP number 888833#.
Phone 1 calls Phone 3---->Press extension 102. After getting through you will hear the Dial
tone, then press the VoIP number 888829#.
Phone 2 calls Phone 1---->Press 888835#. After getting through you will hear the Dial tone,
then press the extension 101.
Phone 2 calls Phone 4---->Press 888835#. After getting through you will hear the Dial tone.
Press outside line 0, then press 87654321.
Phone 3 calls Phone 1---->Press 888835#. After getting through you will hear the Dial tone,
then press the extension 101.
Phone 3 call Phone 4---->Press 888835#. After getting through you will hear the Dial tone.
Press outside line 0, then press 87654321.
Phone 4 calls Phone 2---->Press 12345678. After getting through you will hear the auto reply
from the PBX, then press the extension 102. After getting through you will hear the Dial
tone, then press the VoIP number 888833#.
Phone 4 calls Phone 3---->Press 12345678. After getting through you will hear the auto reply
from the PBX, then press the extension 102. After getting through you will hear the Dial
tone, then press the VoIP number 888829#.
Note: # indicates termination of the phone number. After pressing #, VoIP is called out
immediately. Or, you may wait 3 seconds if you do not press #. This example is
intercommunication with one SIP Proxy Server. For the applications of Direct IP Call and
Intercommunication with different SIP Proxy Servers please refer to 3.3.3 Example
3(Basic Calling Method). The VoIP call can also wok with VPN, please refer to 3.3.4 P
Example 4(VoIP over VPN).
Port Number
Port1(ISDN-NT)
Port5(ISDN-TE)
Port1(ISDN-NT )
84
Phone Number
Proxy
888833
iptel
888835
iptel
888829
iptel
Vigor3300V+ Series User's Guide
Codec
G.729A
G.729A
G.729A
