Downstream Rate
Upstream Rate
Type
Physical Mode
IP Mode
2.2.1 Static Mode
You can manually assign a static IP address to the WAN interface and complete the
configuration by applying the settings and rebooting your router. Choosing Static as the IP
mode, you will see the following page.
All the settings here are set by privately. Your ISP will not provide these settings.
Use the default Mac address stored originally in router.
User Defined MAC-
Use a MAC address defined by the user.
Assign the downstream rate for this WAN interface. The default
value is 102400 kbps (100 Megabit). This setting is very important
for Vigor3300 Series incoming buffer adjustment. If you use a DSL
subscriber service with a 2Mbps downstream, please set the
downstream rate setting with 2Mbps.
Assign the transmission rate for this WAN interface. The default
value is 102400 kbps (100 Megabit). This setting is very important
for Vigor3300 Series outgoing buffer adjustment. If you use a DSL
subscriber service with a 256Kbps downstream, please set the
downstream rate setting with 256Kbps.
Select a connection type for this WAN interface. Currently, there is
only one setting offered for you to choose - Fast Ethernet.
Select connection speed mode for this WAN interface. There are
auto negotiation, full duplex, and half duplex of either 10M or
100M speed options for the WAN Interface.
You have to select an appropriate WAN connection type for
connecting to the Internet through this router according to the
settings that your ISP provided. Select an IP mode for this WAN
interface. There are four available modes for Internet access, Static,
DHCP, PPPoE, and PPTP. On this page you may configure the
WAN interface to use Static (fixed IP), DHCP (dynamic IP
address), PPPoE or PPTP. Most of the cable users will use the
DHCP mode to get a globally reachable IP address from the cable
host system.
14
Vigor3300V+ Series User's Guide
