Line3(3)
Phone1
Start to dial by using telephones.
Phone 1 calls Phone 2---->Press 3, after hearing the dial tone press VoIP number 888829#.
Phone 2 calls Phone 1---->Press 888833#, after getting through you will hear the auto reply
from the PBX. Then press the extension 101.
Note: # indicates termination of the phone number. After pressing #, VoIP is immediately
called out. Or you may wait 3 seconds if you do not press #.
This example is the intercommunication with one SIP Proxy Server. For the applications of
Direct IP Call and Intercommunication with different SIP Proxy Servers please refer to 3.3.3
Example 3(Basic Calling Method). The VoIP call can also wok with VPN, please refer to
3.3.4 Example 4(VoIP over VPN).
Also you can set up the Speed Dial entry. To accommodate the extension please set up
888829 to 291, 888833 to 331. You may refer to the figures shown below and 3.3.3
Example 3(Basic Calling Method).
Example of lines connections
PBX
Outside Lines
Inside Lines
76
Phone Number
888833
101
Vigor3300V+ Series User's Guide
