For Default Configuration
Click Default tab. The following page of default configuration will be shown:
Profile Status
Name
Authentication
PreShared Key
Security Protocol
Set the initialization of IPSec Tunnel with this profile settings.
Enable – Choose this one to invoke this profile manually. In
addition to select Enable, you have to click Initiate under the
page of VPN-IPSec Tunnel-Policy Table.
Always-On – Choose this one to invoke this profile
automatically by the system for every 30 seconds.
Disable – Choose this one to inactivate this profile.
The name for VPN connection (ex. "VPN1"). The maximum
length of name is 20 characters including spaces.
The authentication to be used by PreShared Key or RSA
Signature.
The shared key for peer identification. The maximum length is
40 characters, including spaces.
AH - Specify the IPSec protocol for the Authentication Header
protocol. The data will be authenticated but not be encrypted.
ESP - Specify the IPSec protocol for the Encapsulating
Security Payload protocol. The data will be encrypted and
162
Vigor3300V+ Series User's Guide
