RS-232/422 Host Port

Includes host port connections and host protocols.

Host Port Connections

Baud Rate, Host Port
Can be used to transfer data faster or to match host port settings.
Usage:
The rate at which the scanner and host transfer data back and forth.
Definition:
<K101,aux port
Serial Cmd:
ID status,daisy chain ID>
Default: 9600
1 = 1200
Options:
2 = 2400
3 = 4800
Parity, Host Port
Only changed if necessary to match host setting.
Usage:
An error detection routine in which one data bit in each character is set to
Definition:
1 or 0 so that the total number of 1 bits in the data field is even or odd.
<K100,baud rate,parity,stop bits,data bits>
Serial Cmd:
Default: Even
0 = None
Options:
Stop Bits, Host Port
Only changed if necessary to match host setting.
Usage:
Definition: One or two bits added to the end of each character to indicate the end of
the character.
Serial Cmd: <K100,baud
Default: One
0 = One
Options:
mode,baud rate,parity,stop bits,data bits,daisy chain
4 = 9600
5 = 19.2 K
6 = 38.4 K
1 = Even
rate,parity,stop bits,data bits>
1 = Two
Chapter 3 Communications
7 = 57.6 K
8 = 115.2 K
2 = Odd
MS-9 Scanner User's Manual
3-3
