Scanner Setup
Automatic Gain Control (AGC)
Important: AGC settings apply to both AGC gain control and symbol detection.
AGC Status
AGC allows the user to specify how automatic gain control sampling will
Usage:
be done.
AGC is the acronym for Automatic Gain Control. AGC increases the depth
Definition:
of field by attempting to maintain signal strength at a constant level
regardless of the range of the bar code symbol.
<K505,AGC
Serial Cmd:
Default: Enabled
0 = Disabled
Options:

Transition Counter

Usage: Can be useful in certain application where extraneous objects in the field
of view might require a higher threshold.
Determines the number of bar/space transitions that are sampled before
Definition:
AGC can be resolved.
<K505,AGC
Serial Cmd:
Default: 14
10 to 255
Options:
MS-9 Scanner User's Manual
4-18
status,transition counter>
1 = Enabled
Status,transition counter>
