Summary of Contents for Microscan EZ Trax QUADRUS EZ
- Page 1 EZ Trax ™ Quick Start Guide Copyright ©2007 Microscan Systems, Inc. P/N 83-200013 Rev B...
- Page 2 • Launch Setup.exe under EZ Trax and follow the prompts. If downloading from the web: • Go to http://www.microscan.com/downloadcenter • Create a new “myMicroscan” member account or, if you are already a member, enter your user name and password. • Click the Download Software link and download the latest version of EZ Trax to a directory of your choice.
- Page 3 Step 3 — Explore the EZ Trax Interface Choose which format to use for output of captured symbol images. Hint: TIFFs and BMPs, while higher resolution than JPEGs, take significantly longer to transfer. Set connection parameters here. Select a location in host memory where EZ Trax can store captured...
- Page 4 Configure Your Reader in ESP (continued) Important: If you will be using the Aux Port for an application other than EZ Trax, you must first set Aux Port Mode, <K101>, to Command Processing, as shown below. (Only the Quadrus MINI and MS-4 support this use of the Aux Port.
- Page 5 Step 6 — Connect to EZ Trax Once you have selected your communications protocol and set connection parameters, click the Connect button at the bottom of the Communications dialog. After you achieve a successful connection, you will see the green CONNECTED indicator on the EZ Trax status bar at the bottom right of the screen.
- Page 6 Set File Storage Parameters (continued) Options Menu The Options dropdown menu allows you to create a Document Memo, set Filename Options, and configure the software to Auto Connect and Start when you open and run EZ Trax. Document Memo Any information you type in the Document Memo field will be shown whenever you click on Document Memo in the Options dropdown menu.
- Page 7 Step 9 — Begin Capturing and Storing Images After all parameters have been configured, you will be able to start capturing and storing images. To begin, click the Capture button, which is located below the File Storage dialog. Important: If your reader is not set to External Edge triggering mode and Rapid Capture mode when you click Capture, the following message will appear: You can open your pre-selected file storage location at any time by clicking the Retrieve button, located to the right of the Capture button.
- Page 8 If you will be using the Aux Port in tandem with the host port, you will need to include a modem cable in your hardware configuration. The following illustration shows the correct cabling for Aux Port operation. Microscan Systems, Inc. 1201 SW 7th St. Renton, WA 98057 USA...
