General Specifications
Appendix A — General Specifications
Key Features
• Multiple symbol and symbology reading
• 3 programmable outputs
• Industrial IP54 rated enclosures
• 2000 scans and decodes per second
• Ultra compact size
• OMR reading option
• Invisible ink option
• Read rate LEDs
Mechanical
Depth: 3.0 in (76.2 mm)
Width: 2.275" (57.8 mm)
Height: 1.625 in. (41.3 mm)
Weight: 11 oz. (311 g)
Environmental
Enclosure rating: IP54
Operating temperature: 0° to 40°C
Storage temperature: –50° to 75°C
(–58° to 167°F)
Humidity: Up to 90% (non-condensing)
Emissions and Immunity
General immunity for light industry:
EN 50082:97
Radiated and conducted emissions of ITE equipment:
EN 55022:98, Class A
Laser Light
Type: Laser Diode
Output Wavelength: 650 nM nominal
Safety class:
CDRH Class II, 1.0 mW max.
Optional: Invisible Ink
MS-9 Scanner User's Manual
A-2
2.275" (57.8 mm)
Receiving Window
Scan Beam Exit
Front View
Side View
3.0" (76.2 mm)
Top View
Figure A-1 MS-9
Dimensions
