Hardware Required
Step 1 — Hardware Required
(Refer to
figure 1-1.)
Item Part Number
FIS-0911-XXXXG
1
2
61-300026-03
3
99-000018-01
4
97-100004-15
5
(90-264 VAC, 24VDC)
99-000017-01
6
a. With either a terminal communications program or Microscan's ESP which runs under Windows
operating system, Windows 98 or higher, including Windows NT and Windows XP.
b. If using another host cable, make certain it does not have RTS/CTS connected to the host.
Caution: If using your own power supply, be certain that it is wired correctly and sup-
plies voltage is within the +10 to 28 VDC limits. Incorrect wiring or voltage can cause
software or equipment failures.
MS-9 Scanner User's Manual
1-2
9
MS-
Host Computer
Cable, Communication, DB-25 Plug to DB-9 Socket,
6 foot.
IB-131 interface Box
Power supply
Optional object detector
1
2
3

Figure 1-1 Hardware Configuration

Description
Laser Scanner
a
b
4
Scanner
Power Trigger
5
6
