Trigger Evaluation Period

The number of trigger events to examine within the trend analysis event.
Definition:
<K810,output on,active state,pulse width,output mode,trend analysis
Serial Cmd:
mode,trigger evaluation
ger>
Default: 0
0 to 255
Options:
Note: For Trend Analysis to function the Number To Output On and the Trigger
Evaluation Period must be 1 or more.

Number to Output On

Sets the number of events (matches, mismatches, noreads, etc. as con-
Definition:
figured by Output On) that must occur before activating the associated
output.
<K810,
Serial Cmd:
mode,trigger evaluation
ger>
Default: 1
Options: 1 to 255
Note: For Trend Analysis to function the Number To Output On and the Trigger
Evaluation Period must be 1 or more.
Note: The number of matches, etc. for this setting does not need to be sequential.
Decodes per Trigger
When Reads/Trigger trend analysis mode is enabled, the Reads per
Definition:
Trigger Threshold value is the minimum number of successful reads
required during a read cycle.
You can determine the expected number of scans during a read cycle by
Helpful
multiplying the enabled Number of Scans per second times the number
Hints:
of seconds in the read cycle.
<K810,output on,active state,pulse width,output mode,trend analysis
Serial Cmd:
mode,trigger evaluation period,number to output
ger>
Default: 0
0 to 65,535
Options:
period,number to output on,decodes per trig-
output on,active state,pulse width,output mode,trend analysis
period,number to output
