Partial Output

Partial Output

In Multisymbol mode, partial output is performed on each separate
Usage:
symbol. For example, if Start Position is set to 3 and Partial Length is
set to 5, the following symbols are transmitted as follows:
1234567890 as 34567
1234 as 34
123456789,abcde as "34567,cde" (two symbols with separator)
12 as [blank]
When enabled, allows you to pre-select portions of symbols to be transmit-
Definition:
ted by the scanner.
Partial Output Status
Serial Cmd: <K703,status,start postion,length>
Default: Disabled
0 = Disabled
Options:
Start Position (Partial Output)
Allows you to determine the first character from the beginning of a sym-
Definition:
bol to transmit.
<K703,status,start
Serial Cmd:
Default: 1
1 to 63
Options:
Length (Partial Output)
Allows you to determine the number of characters to be transmitted.
Definition:
<K703,status,start postion,length>
Serial Cmd:
Default: 63
1 to 63
Options:
MS-9 Scanner User's Manual
8-8
1 = Enabled
postion,length>
