Matchcode Type

Matchcode Type

Note: If Matchcode is set to Wild Card or Sequential, Number of Symbols will
default back to (if set to any number greater than 1).
1
Allows the user to choose the way that master symbols will be com-
Definition:
pared with subsequently scanned symbols.
Note: First set Triggering Mode to
<K223,matchcode
Serial Cmd:
tion,match length,wild card character,sequence on noread,sequence on
mismatch>
Default: Disabled
Options: 0 = Disabled
1 = Enabled
Options
Has no effect on operations.
Enabled
Instructs the scanner to compare symbols or portions of symbols with the master sym-
bol.
Wild Card
Allows the user to enter user defined wild card characters in the master symbol.
Sequential
Instructs the scanner to sequence after each match (numeric only) and compare sym-
bols or portions of symbols for sequential numbers.
MS-9 Scanner User's Manual
6-4
External
type,sequential matching,match start posi-
2 = Wild Card
3 = Sequential
or Serial.
