Aux Port Mode - Microscan MS-9 User Manual

RS-232 Auxiliary Port
Allows the user to select the last one or two bits in each character to indi-
Definition:
cate the end of the character.
<K101,aux port mode,baud
Serial Cmd:
ID status,daisy chain ID>
Default: One
0 = One
Options:
Data Bits, Aux Port
Only changed if necessary to match host setting.
Usage:
Definition: Number of bits in each character.
Serial Cmd: <K101,aux port mode,baud rate,parity,stop
ID status,daisy chain ID>
Default: Seven
0 = Seven
Options:

Aux Port Mode

Note: The aux port interacts only with the host port via the 25-pin port except when in
Daisy Chain mode. When in Daisy Chain mode, the aux port will also interact with the
configuration port (9-pin port) or the wiring box network ports.
Determines the flow of data between the auxiliary port device(s), the
Definition:
scanner, and the host.
<K101,aux port
Serial Cmd:
ID status,daisy chain ID>
Default: Disabled
0 = Disabled
Options:
1 = Transparent
2 = Half duplex
MS-9 Scanner User's Manual
3-10
rate,parity,stop
1 = Two
1 = Eight
mode,baud rate,parity,stop bits,data bits,daisy chain
3 = Full duplex
4 = Daisy chain
5 = Command Processing
bits,data bits,daisy chain
bits,data bits,daisy chain
