RS-232/422 Host Port

RS-232/422 Host Port
The host port can be configured with RS-232 and RS-422 connections.

Host Port Connections

These settings define the basic transmission speeds and digital standards that ensure
common formatting.

Baud Rate, Host Port

Usage: Can be used to transfer data faster or to match host port settings.
Definition: The rate at which the reader and host transfer data back and forth.
Serial Cmd: <K100,baud
Default: 115.2K
0 = 600
Options: 3 = 4800
6 = 38.4K

Parity, Host Port

Usage: Only changed if necessary to match host setting.
An error detection routine in which one data bit in each character is set to 1
Definition:
or 0 so that the total number of 1 bits in the data field is even or odd.
Serial Cmd: <K100,baud rate,parity,stop bits,data bits>
Default: None
Options: 0 = None

Stop Bits, Host Port

Usage: Only changed if necessary to match host setting.
One or two bits added to the end of each character to indicate the end of
Definition:
the character.
Serial Cmd: <K100,baud
Default: One
Options: 0 = One
2-4
rate,parity,stop bits,data bits>
1 = 1200
4 = 9600
7 = 57.6K
1 = Even
rate,parity,stop bits,data bits>
1 = Two
2 = 2400
5 = 19.2K
8 = 115.2K
2 = Odd
Quadrus EZ Reader User's Manual
