C a l i b r a t i n g a S c r o l l e r
You can calibrate the center point of any frame in a scroller using the calibrate feature. This will
ensure that color scroll frames will be centered over the aperture of the fixture when you advance
a color scroll frame-by-frame. You can do this using the virtual encoders or the encoder LCD.
Calibrating a scroller is normally done from the live display.
N o t e :
To calibrate a scroller from the virtual encoders:
Step 1: In the browser, navigate to Virtual Controls>Encoder. A new window will open in
the CIA.
Step 2: Select {Open as Primary Display} in the CIA. Virtual encoders will open on the
display screen.
Step 3: Select the channel of the scroller you wish to calibrate.
Step 4: Press the [Color] encoder button to the upper right of the LCD. Multiple presses may
be required before the scroller encoder is visible in the virtual encoder display.
Step 5: Use the encoder to move all the way to the last frame of the scroller.
Step 6: Watch the scroller and continue adjusting the frame until it is centered in the desired
position.
Step 7: Click {Calibrate} in the virtual encoder display. The new center position is now stored
for the selected channel.
Step 8: Click {Last} in the virtual encoder display to move to the center point of the previous
frame.
Step 9: Visually verify if the center point of the new frame is accurate. If it is, press {Last} again
to move to the previous frame in the scroll. If not, follow the calibration procedure
again.
Step 10: Repeat steps 6-9 until you have calibrated all of the frames.
Step 11: Press [Live] or [Blind] to close the virtual encoder display.
You can also calibrate from the encoder LCD. This eliminates the need for the virtual encoder
display.
78
It is recommended that you calibrate your scroller frames starting with the last
frame and working backward to the first frame. This will help ensure a complete
and accurate calibration.
Calibration may need to be performed when you initially patch a scroller and may
need to be adjusted through the course of operation as spring tension changes in
a color scroller
Ion Operations Manual
