7.2 Using LPD
Configuration
Hunt groups: Hunt groups are supported on IOLAN+ for
printing. To use this, use the same number in
the Port Setup local port field (i.e. 1006).
IOLAN+ can be setup for receiving print jobs via LPD and
this is a very simple method. It works for both Windows
and Unix systems.
** Administrator **
Hardware
Speed [9600 ]
Parity [None]
Bit [8]
Stop [1 ]
Break [Disabled] IP Addresses
Monitor DSR [No ]
Monitor DCD [No ]
User
Name [LPD_printer
Terminal type [
TERM [
Video pages [0]
CLI/Menu [Menu]
Reset Term [No ]
Figure 27 LPD printing - Port Setup Menu screen.
The following fields are important:
Flow control: Set your IOLAN+ port flow control to Hardware .
Then set your printer to use 'DTR Pacing' or
'Hardware' or 'Ready/Busy' flow control. Use
the RS-232 printer cable pinout shown in the
Cabling Guide (Appendix C), as this will save a
print job if the printer is turned off or the cable
becomes detached.
PORT SETUP MENU
Flow ctrl
Flow ctrl [Hardware]
Input Flow [Enabled ]
Output Flow [Enabled ]
Src [ ]
Dst [ ]
Options
] Keepalive [No ]
] Rlogin/Telnet [Telnet]
] Debug options [No ]
Map CR to CR LF [No ]
Hex data [No ]
Secure [No ]
MOTD [No ]
Printing
®
REMOTE-ADMIN
Keys
Hot [^]] Intr [^C]
Quit [^@] Kill [^U]
Del [^@] Sess [^@]
Echo [^@]
Mask [ ]
Access
Access [Remote ]
Authentication [None ]
Mode [Raw ]
Connection [None ]
Host [ ]
Remote Port [0 ]
Local Port [515 ]
