2.4 Communicating
via a
Terminal or
PC
Here is the sequence to use:
arp -s 192.168.209.8 00:80:d4:00:33:4e
telnet 192.168.209.8
password>
local>
At the password prompt, just hit
The IP address still needs to be configured on the unit (ARP
has only allowed you to connect to the unit so far).
Note: If there are any errors, recheck both the IP and
Ethernet addresses you keyed in (this is the most common
error here). See Troubleshooting & Maintenance
(Appendix B) for more information on problems.
You can now skip the next section and go straight to section
2.5, The Menu System.
You can connect to IOLAN+ using a terminal or PC (with a
terminal emulation package such as Hyperterm).
Connect a terminal or your PC to port 1. The IOLAN+ serial
ports are DTE type RS-232 ports. When connecting a terminal/
PC directly (without modems), the RS-232 signals need to be
crossed over ('null modem' cable). See the Cabling Guide
(Appendix C) for pinout information.
For a terminal/PC to communicate with a server, set it to the
following: 9.6 kbps, eight data bits, one stop bit, software
flow control, no parity.
After powering up IOLAN+, you are prompted to enter a
'Local login:>'. You can just hit any character and
point (the character is required).
Installing your IOLAN+
since this is not set yet.
at this
