9.7 Gateway
Menu
The Gateway Menu allows the IOLAN+ to make use of a
gateway (I P router) on the network. This allows flexible
internetworking.
** Administrator **
Entry Destination
1 [default
2 [
3 [
4 [
and so on..
________________________________________________________________________________
Figure 39: Administration - Gateway Menu.
The parameters are as follows:
This field specifies either the destination
Destination
network or host address.
This field defines the gateway (IP router) host
Gateway
address. The gateway host must be attached to
the same network as IOLAN+.
This field allows the administrator to define a
Netmask
mask that IOLAN+ will use to mask out packets
from other networks using the same Ethernet.
The valid Netmask fields are:
class a Only class a addresses are allowed across
the gateway.
Only class b addresses are allowed across
class b
the gateway.
class c Only class c addresses are allowed across
the gateway.
The Menu Interface
GATEWAY MENU
Gateway Netmask
] [204.17.209.254 ] [default
] [ ] [
] [ ] [
] [ ] [
