+ - User and Administration Guide
IOLAN
3.3 Making a
Connection
30
If you are using initiated connections, you will not see the
IOLAN+ menus. Instead, you see the login prompt of the
host you assigned in the host field of the Port Setup Menu .
However, if your connection field is set to None , the
Connections Menu appears. You are now ready to make
connections.
From the Connections Menu press the
*** FREE *** session to display the Commands menu. Select
the Telnet field and press the
Name: IOLAN
Connection
________________________________________________________________________________
Figure 17: Connections Menu - Commands pop-up Menu.
This produces a pop-up menu allowing the choice of the host
machines that are configured in the host table. To select a
host, move the cursor down to the required name then press
the key. At this point the unit attempts to make a
connection across the network to the indicated host using the
telnet protocol.
If it succeeds, the host machine's login prompt is displayed.
There may be an error in the configuration if the connection
cannot be established.
key.
CONNECTIONS MENU
Host
1 *** FREE ** === Commands ===
2 *** FREE ** | Telnet
3 *** FREE ** | Rlogin
4 *** FREE ** | Port
| Admin mode ^A|
| CLI
| Lock
| Logout
================
key on a
Terminal: 7
^T|
^R|
^P|
|
|
^D|
