Server Statistics Pop-Up Menu - Perle IOLAN + Rack User And Administration Manual

+ - User and Administration Guide
IOLAN
ETH/TTY/
GATEWAY
IP/ICMP/UDP
TCP
Users
126
** Administrator **
=== ETHERNET ===
Tx: Pkts: 395 Errors:
Retries : 0 Resets:
Rx: Pkts: 866 Bufs: 170/300
Prot: 101 Miss:
=== SERIAL LINES ===
Tx: chars: 6,561
Rx: chars: 2,752
Malformed: 0
Buffer failures: 0
=== ROUTING STATISTICS ===
bad redirects:
unreachable:
Uptime: 0 days 00:41:49 hours Memory free:182768 ======================
________________________________________________________________________________
Figure 51: Server Statistics pop-up Menu.
All of the IOLAN+ statistics screens are now accessible
through this Statistics pop-up menu. Pressing
the IOLAN+ statistics screens displays the same pop-up menu.
A summary of each is provided and then the most important
screens are briefly described:
This is a general overview of Ethernet activity, serial activity
and gateway stats. It shows characters passed and uptime.
This is a comprehensive screen of networking protocol stats
for IP, ICMP and UDP. You can identify bad IP packets
coming in from your network.
This is a comprehensive screen of TCP protocol stats. You
can identify bad TCP packets coming in from your network.
This is a good menu for showing port and control signal
status. You can identify status on each ports control signals.
SERVER STATISTICS
0 Collisions: ===== Statistics =====
0 Busy: | ETH/TTY/GATEWAY
No Bufs: | IP/ICMP/UDP
0 Busy: | TCP
| Users
| Framed Link Status |
psec: 2 | Netstat
psec: 1 | Gateway
Lost: 0 OverRuns: | Slip
| Clear counters
| Restore counters
| Port Status
0 dynamic: 0 ne | Line Status
0 wild card: 0 | LPD Status
| PPP Status
REMOTE-ADMIN
|
|
|
|
|
|
|
|
|
|
|
|
|
in any of
