Remote Access Systems Screen - Perle IOLAN + Rack User And Administration Manual

+ - User and Administration Guide
IOLAN
6.4 Remote
Access
Systems
50
This screen is used to define a remote system (up to 16
entries per IOLAN+), a phone number, login script, etc.
There are a lot of similarities between this screen and the
UUCP systems file under Unix.
** Administrator **

REMOTE ACCESS SYSTEMS SCREEN

Sitename [206.189.134.2
User name [corp
Password [whodunit
Device type [modem1
Service type [PPP ]
Inactivity [5 ]
Phone number [
Login-script [
________________________________________________________________________________
Figure 24: Remote Access Systems Screen.
The following fields are important:
Sitename: The IP name or IP address of the remote site
IOLAN+ will be calling.
User name: The user name required by the remote system
for logging in. You may use the \u in your login
script in lieu of the full name.
Password: The above user name's password as required by
the remote system. You may use the \p in your
login script in lieu of the full password.
Device type: The name of the modem device as defined in the
Remote Access Systems Screen . You may have
several ports setup with the same device type, and
the dialer will use the first available.
If a device for dialing out is not available,
IOLAN+ will return an ICMP 'host unreachable'
message (ICMP type 3 code 1).
]
]
]
]
REMOTE-ADMIN
]
]
