IOLAN
22
All of the procedures are based around the Port Setup Menu .
This is accessed through the Administration Menu (password
level). Remember, that if you are not in the password level,
you can only view the information, not change it.
Here is the Port Setup Menu :
** Administrator **
Hardware
Speed [9600 ]
Parity [None]
Bit [8]
Stop [1 ]
Break [Disabled] IP Addresses
Monitor DSR [No ]
Monitor DCD [No ]
User
Name [
Terminal type [ansi
TERM [
Video pages [0]
CLI/Menu [Menu]
Reset Term [No ]
________________________________________________________________________________
Figure 14: Port Setup Menu.
This menu allows the user to set up all the parameters
associated with a port. The administrator can alter the set-up
of any port on the communications server while a user can
only alter the set-up for their own port.
This menu is divided into the following sections:
Hardware: Defines port type and is used for setting up the
hardware configuration of the modem, terminal,
printer or PC session. This section is always used.
User: Defines various user parameters such as name and
terminal type. Most fields are used in this section.
Flow Control: Defines the various flow control options used by
IOLAN+. This section is always used.

PORT SETUP MENU

Flow ctrl
Flow ctrl [XON/XOFF]
Input Flow [Enabled ]
Output Flow [Enabled ]
Src [ ]
Dst [ ]
Options
] Keepalive [No ]
] Rlogin/Telnet [Telnet]
] Debug options [No ]
Map CR to CR LF [No ]
Hex data [No ]
Secure [No ]
MOTD [No ]
REMOTE-ADMIN
Keys
Hot [^]] Intr [^C]
Quit [^@] Kill [^U]
Del [^@] Sess [^@]
Echo [^@]
Mask [ ]
Access
Access [Local ]
Authentication [None ]
Mode [Raw ]
Connection [None ]
Host [ ]
Remote Port [0 ]
Local Port [10006]
