3.2 Host Table
Setup
Monitor DSR: You can set this field to Yes if you wire the
terminal's DTR signal pin 20 (DB25) to the
IOLAN+'s DSR signal pin 3 on the RJ45
connector ( see Cabling Guide for DB25 pin
assignments). When you turn the terminal off, it
will reset the IOLAN+ port, which tells the Unix
host to kill the user's processes.
In order for IOLAN+ to connect easily to machines on the
network it must know the IP addresses of the other
computers. IOLAN+ can have its own internal table of IP
addresses set up in the host table. This is a 'local' naming
system only. IOLAN+ can also use the name server utility of
your Unix system (consult your Unix system manual and
section 2-6, Tips ).
The Host Address Menu is accessed from the Administration
Menu by selecting the host entry. The host table can contain
up to 10 addresses. Each entry consists of a host name and
its corresponding IP address.
** Administrator **
Entry Host name
1 [fred ]
2 [astro ]
3 [router ]
4 [perle ]
and so on...
________________________________________________________________________________
Figure 16: Host Address Menu Screen.
You can fill in an entry (both the name and the IP Address)
for your host machines and then save the values by pressing
the key.
Terminals on Multi-user Systems
HOST ADDRESS MENU
IP Address
[204.17.209.70 ]
[204.17.209.6 ]
[204.17.209.254 ]
[204.17.209.1 ]
REMOTE-ADMIN
