Commands Pop-Up Menu (Server Confign) - Perle IOLAN + Rack User And Administration Manual

Port Setup Menu
and Beyond
Subnet mask [
Ethernet address [00:80:d4:00:9e:
Language [English ]
Identification [
Lock [Disabled]
Password limit [5
CR to initiate [Yes ]
SNAP encoding [Disabled]
Figure 13: Commands pop-up menu (server confign).
Select the Save & Exit field and press the
options are Quit & Exit, which does not save the changes
before exiting this menu, Values, which will display the
optional values for this field if available, and Cancel, which
will take you back to this screen for more editing.
You have now set up the unit with a new IP address. This
should be confirmed with the message:
IP CHANGED—PLEASE REBOOT
Reboot the communications server to activate the new IP
address using the reboot command. The IP address and/or
subnet mask are the only parameters that when changed
necessitate rebooting.
Your communications server is now ready to configure for
terminals on multi-user systems or modems, printers and
other devices. The next sections deal with each of these.
If you've got a good feel for the menu system, you should
proceed to the section appropriate for your application.
If you'd like a full review of the menu system refer to section
9, The Menu Interface later in this guide. For more
information about the Command Line mode, consult
Command Line Interface (Appendix A) .
Installing your IOLAN+
]
== Commands ===ernet interface [AUTO
| Save & Exit |
| Quit & Exit |
| Values |
] | Cancel |
===============
]
]
key. Other
21
