IOLAN
9.14 Server
Configuration
Menu
Identification
Fields
104
This menu allows the user to define all of the main IOLAN+
system parameters.
** Administrator **
Name [IOLAN+
IP address [204.17.209.8
Subnet mask [
Ethernet address [00:80:d4:00:9e:a1]
Language [English ]
Identification [
Lock [Disabled]
Password limit [5
CR to initiate [Yes ]
SNAP encoding [Disabled]
Boot host [204.17.209.1
Boot file [
Init file [
MOTD file [
Domain name [perle.com
Name server [astro
WINS server [fred
________________________________________________________________________________
Figure 48: Server Configuration menu.
The menu as displayed can be divided into four logical
sections: identification fields, general admin, downloading
and domain naming.
This field determines the name of IOLAN+ and
Name
is displayed in the bottom right hand corner of
the menus.
This field holds the IP address of IOLAN+. If the
IP address
IP address of IOLAN+ is altered then the unit
must be rebooted to permanently save changes.
This field allows the administrator to define a
Subnet mask
mask that IOLAN+ uses to mask out packets
from other networks using the same ethernet.
SERVER CONFIGURATION
] Debug mode
]
]
Ethernet interface [AUTO
]
] Boot diagnostics [Enabled ]
]
] NS Port
]
REMOTE-ADMIN
[0 ]
]
]
]
]
]
[53 ]
