9.10 Lines Menu

Access
This option allows the administrator to configure all of the
parameters for any of the ports. The parameters accessible
are exactly the same as those in the Port Setup Menu , but
from these menus you can configure a set of parameters for
all of the ports. Selecting this option brings up the Lines
pop-up menu as shown below.
** Administrator **
access Remote System Access (PPP).
change Change login and/or admin password.
gateway Examine/modify gateway table.
host Examine/modify host table.
kill === Lines ===connections on serial line.
line | Access |configuration organised by line.
port | Flow ctrl |configuration organised by port.
quit | Hardware |
reboot | Network |rver.
server | Options |odify Server parameters.
stats | Terminal |erver statistics.
trap =============odify SNMP Trap parameters.
________________________________________________________________________________
Figure 41: Administration Menu - LInes pop-up menu.
Each of the options displayed in the pop-up menu brings up
another menu. These are detailed in the following sections.
The Access section shows and allows changes to the name,
access, authentication and mode fields. These fields are
described in The Port Menu - Access Section above.
** Administrator **
TTY Name Access
1 [mark ] [Dynamic] [Host ]
2 [alan ] [Dynamic] [Host ]
Figure 42: Lines - Access Menu.
ADMINISTRATION MENU
connections menu.
ACCESS MENU
Authentication Mode
[Telnet]
[Telnet]
The Menu Interface
REMOTE-ADMIN
REMOTE-ADMIN
101
