IOLAN
5.1 User
Authentication/
Logging
40
To improve access security, IOLAN+ has a mechanism for
authenticating users before allowing them access. This is
accomplished by prompting the user for a Login ID and a
password. IOLAN+ will then attempt to login to a specified
host using that ID and password. If successful, the user is
authenticated and allowed access. Otherwise, the call is
dropped. IOLAN+ will also log events such as logins,
logouts, connections and disconnections, and power ups.
This feature is enabled when you set the Authentication field
to host in the Port Setup Menu.
The following is the host authentication setup (via the Access
section of the Administration Menu ):
** Administrator ** HOST AUTHENTICATION AND LOGGING
Auth Host [204.17.209.1
Authentication Port
Login Prompt
Password Prompt
Success Indication String [Last
Failure Indication String [incorrect
Maximum Login Attempts
Login Timeout (seconds)
Disconnect Probe
Log Username [iolan
Log File [iolan.log
Log Power Up/Down
Log Port Connect/Disconnect [Yes]
________________________________________________________________________________
Figure 20: Host Authentication and Logging screen.
The following fields are important:
Auth Host:
[23 ]
[ogin: ]
[ssword: ]
]
]
[3 ]
[60]
[No ]
]
[Yes] Log User Login/Logout
Log User Service Start/Stop [Yes]
The IP Address/Name of the host that
IOLAN+ attempts to login to for
authenticating users.
REMOTE-ADMIN
]
]
[Yes]
