The TERM field
Gateway Tables
32
The TERM field in the Port Setup Menu can be used to pass
the terminal type information to the host. The terminal type
field is local to the IOLAN+ but will be passed to the host.
The TERM field can override the information being sent to
the host about the type of terminal. This allows you to
customise information being passed to the host. For
example, a user could encode the physical location into this
field (i.e. tty16) and then extract that at the host end to
determine which port the user has logged in on (i.e. port 16).
When the host and IOLAN+ are connected via a gateway
router, a connection is not possible until the gateway table
has been updated with the IP address of the local gateway
machine. See section 9.7, the Gateway Menu section of
The Menu Interface .
