Server Statistics Screen - Port Activity; Server Statistics Screen - Line Status - Perle IOLAN + Rack User And Administration Manual

Line status
LPD Status
PPP Status
** Administrator **
====RECEIVED====
PORT PER SEC TOTAL
1 0 7
2 0 6
3 0 0
4 0 24
5 0 0
6 0 2075
7 0 0
8 0 688
________________________________________________________________________________
Figure 56: Server Statistics screen - port activity.
This is a good screen for spotting baud rate and parity errors
which if malformed is rapidly incrementing.
** Administrator **
PORT MALFORMED LOST
1 0 0
2 0 0
3 0 0
4 0 0
5 0 0
6 0 0
7 0 0
8 0 0
________________________________________________________________________________
Figure 57: Server Statistics screen - line status.
This screen allows you to check the status of your LPD
connections and print queues.
This shows the PPP negotiation progress status and
established PPP connections.
Troubleshooting & Maintenance
SERVER STATISTICS
===========TRANSMITTED===========
XON XOFF PER SEC
14 0 1
14 0 0
14 0 0
15 0 0
14 0 0
14 0 0
14 0 0
14 0 0
SERVER STATISTICS
OVERRUN BREAK
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
REMOTE-ADMIN
TOTAL
3837
3
3
3
0
2075
688
0
REMOTE-ADMIN
129
