Connections
Menu
________________________________________________________________________________
v4.02 a CDi
Figure 8: Connections Menu.
The firmware version of IOLAN+ is located on the lower left
hand portion (in this example, version 4.02). The wording
'REMOTE-ADMIN' in the upper right signifies you are
remotely telneted into IOLAN+ (and will read 'Terminal: 1' if
you are using a terminal/PC into port 1.)
The keys used to move about in the menus depend on the
terminal emulation you are using. The arrow keys should all
work. The TAB key is very important for moving between fields.
Backspace and DEL should work, but depend on the emulation.
ESC (the escape key) will move you back one menu.
Note: If there is a problem with your emulation, you can try
a different emulation mode. See Troubleshooting &
Maintenance (Appendix B) for more information.
An accelerator key can be used to jump to an option within
a menu and is the first letter of the option.
Select connection '1' on the Connections Menu and press
the key. The Commands pop-up menu is displayed.
There are a number of options available from this menu.
Installing your IOLAN+

CONNECTIONS MENU

Connection Host
1 *** FREE ***
2 *** FREE ***
3 *** FREE ***
4 *** FREE ***
REMOTE-ADMIN
IOLAN+
