Chapter 1. General Information
1.1 Supplying Power to the Instrument
1/4-Turn Screw (CW to close, CCW to open)
Accessory Mounting Screw
Slot
Power ON/OFF
Receive Probe
Connection
Pulse/Transmit Probe
Connection
Battery Charger
Connection
1/4-Turn Screw (CW to close, CCW to open)
Figure 1: Rear and Side Views of the USM Go Case
2
USM Go Operator's Manual
