GE Ultrasonic USM Go Operator's Manual page 168

Appendix C. EN 12668 Specifications
Paragraph Parameter
9.4.2 Loaded Pulse Voltage
150
Table 2: EN 12668-1:2000 Specifications (cont.)
LSL Typ.
-140 -156
-139 -154
-171 -190
-171 -190
-103 -114
-102 -113
-115 -128
-115 -128
-167 -186
-167 -185
-209 -232
-209 -232
-185 -206
-185 -205
-211 -234
-211 -234
USL Units Test Conditions
-172 V Damping = 50, Voltage = Low, Energy = Low, RepRate = 15
-169 V Damping = 50, Voltage = Low, Energy = Low, RepRate = 2000
-209 V Damping = 1000, Voltage = Low, Energy = Low, RepRate = 15
-209 V Damping = 1000, Voltage = Low, Energy = Low, RepRate = 2000
-125 V Damping = 50, Voltage = Low, Energy = High, RepRate = 15
-124 V Damping = 50, Voltage = Low, Energy = High, RepRate = 2000
-141 V Damping =1000, Voltage = Low, Energy = High, RepRate =15
-141 V Damping =1000, Voltage = Low, Energy = High, RepRate =2000
-205 V Damping =50, Voltage = High, Energy = Low, RepRate =15
-204 V Damping =50, Voltage = High, Energy = Low, RepRate =200
-255 V Damping =1000, Voltage = High, Energy = Low, RepRate =15
-255 V Damping =1000, Voltage = High, Energy = Low, RepRate =2000
-227 V Damping =50, Voltage = High, Energy = High, RepRate =1
-226 V Damping =50, Voltage = High, Energy = High, RepRate =2000
-257 V Damping =1000, Voltage = High, Energy = High, RepRate =15
-257 V Damping =1000, Voltage = High, Energy = High, RepRate =2000
USM Go Operator's Manual
