Chapter 2. Instrument Setup
2.5.1 Setting the A-Scan Range (cont.)
To set the A-Scan range:
In the ACQUIRE menu, activate the RANGE submenu using the joystick (
1.
2. Use the joystick (
are made with the function toggle, while fine adjustments are made with the joystick. When "RANGE" appears in all capital letters,
coarse adjustments are being made, while fine adjustments occur when "range" appears in all lower-case letters.
3. Press the function toggle or move the joystick (
Note: Pressing both buttons on the Function Toggle simultaneously resets the RANGE to the default value of 10.000 in.
4. After completing your selection, move the joystick up or down (
52
) to select the function titled RANGE, which has both coarse and fine adjustment modes. Coarse adjustments
) to change the range setting. Values from 0.040 to 1100 in. are allowed.
).
) to navigate away from this function.
