Chapter 3. Making Measurements

This chapter explains how to configure the USM Go flaw detection and thickness measurement capabilities. It then explains how to make
ultrasonic measurements.
3.1

Configuring Gate A and Gate B

Setting the position and the characteristics of Gate A and Gate B is the first step in configuring the instrument for flaw detection or material
thickness measurements. The GATE A and GATE B submenus control the location of Gate A and Gate B, while the EVAL and CONFIG2
submenus in the SETUP menu control the operating characteristics for the gates.
In the ACQUIRE menu, activate the Gate A or Gate B submenu using the joystick (
1.
2. Choose the desired function from the available options.
