Logging In Through Nms; Introduction; Connection Establishment Using Nms - 3Com Switch 4800G 24-Port Configuration Manual

6

Introduction

Connection
Establishment Using
NMS
L
OGGING IN
You can also log in to a switch through an NMS (network management station),
and then configure and manage the switch through the agent module on the
switch.
The agent here refers to the software running on network devices (switches)
■
and as the server.
SNMP (simple network management protocol) is applied between the NMS
■
and the agent.
To log in to a switch through an NMS, you need to perform related configuration
on both the NMS and the switch.
Table 19 Requirements for logging in to a switch through an NMS
Item Requirement
Switch The IP address of the management VLAN of the switch is configured. The route
between the NMS and the switch is available. (Refer to the module "IP Addressing
Configuration" on page 121 and "IP Routing Overview" on page 241 for more.)
The basic SNMP functions are configured. (Refer to the "SNMP Configuration" on
page 931 for more.)
NMS The NMS is properly configured. (Refer to the user manual of your NMS for more.)
Figure 21 Network diagram for logging in through an NMS
Network
NMS
T
HROUGH
Switch
NMS
