Error Message >

Before borderless printing, move the blue platen switch.

The blue Switch on the platen was set to the side
opposite ● when a borderless print job was re-
ceived.

Blue platen switch is dirty.

The blue Switch on the platen is dirty.

Move the blue platen switch No.xx to the right. (xx represents a number)

The printer has detected that the blue Switch on the
platen needed in maintenance during printing is set
away from the ● mark.

Cannot adjust paper feed.

The Printhead nozzles are clogged.
13
Highly transparent film is loaded
that cannot be used for automatic
feed amount adjustment.
1112

Check printed document.

The Printhead nozzles are becoming clogged.
Before borderless printing, move the blue platen switch.
Messages regarding printing or adjustment
Cause
Cause
Cause
Cause
Execute Adj. Quality again, as follows.
1. Press the OK button to clear the error.
2. Print a test pattern to check the nozzles.
3. Clean the Printhead if the nozzles are clogged.
4. Execute Adj. Quality again.
Press the OK button to clear the error, and then adjust the feed amount manually.
(See "Manual Banding Adjustment (Adj. Quality).")
Cause
>
Before borderless printing, set the blue Switch on the platen to
the ● side.
(See "Setting the Blue Switch on the Platen.")
Corrective Action
Open the Top Cover and clean the blue Switch on the platen.
(See "Cleaning Inside the Top Cover.")
Set blue platen Switch of the indicated number toward the ●
side.
(See "Setting the Blue Switch on the Platen.")
Corrective Action
(See "Checking for Nozzle Clogging.")
(See "Cleaning the Printhead.")
(See "Automatic Banding Adjustment (Adj. Quality).")
Corrective Action
If printing is faint, clean the Printhead.
(See "Cleaning the Printhead.")
Corrective Action
→P.1078
→P.1040
Corrective Action
→P.1011
→P.1012
→P.857
→P.859
→P.1012
→P.1078
iPF8300S
