Paper Loaded Askew; Cannot Feed Paper - Canon iPF8300S User Manual

Paper loaded askew.

Paper loaded crooked was detected when the paper was advanced.
Important
• To disable this message (if it is displayed repeatedly despite reloading paper, for example), choose Off or
Loose in the Skew Check Lv. setting of the printer menu. However, this may cause jams and printing prob-
lems because paper may be askew when printed. Also, the Platen may become soiled, which may soil the
back of the next document when it is printed.

Cannot feed paper.

Cause
Paper could not 1. Lift the Release Lever and remove the jammed paper.
be advanced cor-
rectly during
feeding.
2. Load paper.
3. Lower the Release Lever.
4. If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen,
(See "Loading Rolls in the Printer.")
(See "Loading Sheets in the Printer.")
iPF8300S
Cause
(See "Clearing Jammed Roll Paper.")
(See "Clearing a Jammed Sheet.")
press the OK button.
Printing will resume, starting from the page on which the error occurred.
Error Message
Corrective Action
Follow these steps to reload the roll.
1. Lift the Release Lever.
2. Adjust the right edge of the roll to make it par-
allel to the orange Paper Alignment Line.
3. Lower the Release Lever.
(See "Loading Rolls in the Printer.")
If this error recurs after you reload the roll, re-
move the Roll Holder from the printer, push the
roll firmly in until it touches the Roll Holder
flange, and reload the Roll Holder in the printer.
(See "Attaching the Roll Holder to Rolls.")
→P.782
Follow these steps to reload the sheet.
1. Lift the Release Lever.
2. Pull out the sheet.
3. Adjust the right edge of the sheet to make it
parallel to the right Paper Alignment Line and
the trailing edge of the sheet to make it parallel
to the paper alignment line under the Paper Re-
tainer.
4. Lower the Release Lever.
(See "Loading Sheets in the Printer.")
Corrective Action
→P.1057
→P.1061
→P.786
→P.813
> Messages regarding paper >
→P.786
→P.813
Paper loaded askew.
