Tear-Off, cont.
6
Route the media through the print unit and push it
inwards as far as it will go.
8
Turn the printhead lift lever to "Closed" position.
Intermec EasyCoder 501 XP – User's Guide
7
This diagram shows the media path.
9
Adjust the position of the green edge guide so the
media is guided with a minimum of play.
Chapter 4
Media Load
21
