Navigating in Setup Mode

Intermec EasyCoder 501 XP – User's Guide
While going through the setup procedure, you are guided by texts
in the printer's display. You can navigate between setup menus,
acknowledge displayed values, select or type new values, etc. by
using the keys on the printer's keyboard.
Note!
An external keyboard cannot be used inside the Setup Mode.
-
1 /. "Left", "right", "up", and "down" refer to the overviews later in
this chapter.
Chapter 7 Setup Mode
Move one menu to the left on the same
1
level .
Move one menu to the right on the same
1
level .
Display error message at test label print-
ing failure.
Move up one level or scroll back in a stack
1
of options .
Move down one level or scroll forward in
1
a stack of options .
Enter numeric values.
Specify negative values (leading position).
Clear erroneously entered values.
Acknowledge and move to next menu.
Perform testfeeds in the Testfeed menu.
Print test labels in the Test Label menu.
Exit the Setup Mode.
Can be used anywhere in Setup Mode.
