Paper Type

The Paper Type parameters control the heat emitted from the
printhead to the direct thermal media or the transfer ribbon in
order to produce the dots that make up the printout image. Start
by choosing between two alternatives:
• Thermal Transfer printing
• Direct Thermal printing (option)
Your choice will decide which parameters to enter next:
Thermal Transfer Printing (option)
This option contains four parameters:
• Ribbon Constant
• Ribbon Factor
• Label Offset
Direct Thermal Printing
This option contains two parameters:
• Label Constant
• Label Factor
Chapter 6 Setting Up the Printer
(default)
(range 50 to 115)
(range 10 to 50)
(range -50 to 50)
(range 50 to 115)
(range 10 to 50)
