RealPresence®Collaboration Server 4000 Hardware Guide
The following LEDs appear on the RTM LAN - 2 ports:
Function Name
LAN 1-2 LEDs
HS LED

RTM ISDN

The following LEDs appear on the RTM ISDN.
.
RMX 4000 RTM ISDN LEDs
Function Name
LAN 1 LEDs
PRI LEDs
ShMC LED
Polycom, Inc.
LED Name LED Color
1 Gb Green
LNK Amber
Blue
LED Name LED Color
1 Gb Amber
LNK Green
OFF
Green
Red
HS Blue
Description
ON with an active network connection, flickers with Packet
activity.
ON when 1Gb connection is online, flickers with Packet
activity.
OFF - Normal.
Flashes - During the startup of a media card and control unit.
Also flashes when the RTM LAN card is powered down.
ON - RTM LAN card may be removed.
Description
ON when 1Gb connection is online, flickers with Packet
activity.
ON with an active network connection, flickers with Packet
activity.
Span x not in use.
Span x is OK.
Span x red alarm (LOS - Loss of Signal)
OFF - Normal.
Flashes - During the startup of a media card and control
4000 unit.
This LED is activated when the MPMx/MPMRx card Hot
Swap functionality initiates a power off routine on the
MPMx/MPMRx cards.
ON - Power on the RTM ISDN card has been switched OFF.
This LED is activated by the card when the MPMx/MPMRx's
card Hot Swap functionality powers off the MPMx/MPMRx
cards.
