RealPresence®Collaboration Server 4000 Hardware Guide
RMX 4000 Front Panel LEDs
Component
MPMx/MPMRx Card
CNTL 4000 Unit
Polycom, Inc.
LED ID LED Color
ERR Red
RDY Greenish
Yellow
ACT Amber
HS Blue
ERR Red
RDY Green
ACT Maroon
HD Red
Description
ON - Major error on card.
Flashes - During card startup.
ON - The card has completed startup successfully,
after the ERR, RDY & ACT LED's have stopped
flashing.
Flashes - During card startup.
ON - At least one participant is connected to a
conference.
Flashes - During card startup.
Flashes - Shut down process initiated by lightly
pulling the CPU ejector levers. This LED flashes in
synchronization with the CNTL 4000's card's HS
LED.
ON - Card is in a power down mode.
Card removal Initiated - The card can be removed
safely once the CPU ejector levers are fully open.
Card Insertion Initiated - If during the startup phase
the blue HS LED remains lit, please ensure that the
card is properly seated in the chassis. If this problem
persists, contact your next level of support.
ON - Major system error. In case of an active alarm
this light is ON, and the RDY green is OFF.
OFF - Normal.
Flashes - During system startup.
ON - CPU card has successfully completed startup.
This light turns green after completing the entire
system configuration.
OFF - Turns OFF when the ERR red LED is
activated.
Flashes - During system startup.
ON - At least one endpoint is connected to the
system.
Flashes - During system startup.
OFF - Normal.
Flashes - Hard disk is active.
