RealPresence Collaboration Server (RMX) 4000 LEDs

The RMX includes LEDs located on the front panel and rear panel. In the front panel, the LEDs reflect the
state of the components. The LEDs on the rear panel indicate the state of the external connections and the
status of the RTM-IP 4000 card.

RealPresence Collaboration Server (RMX) 4000 Front Panel LEDs

The following items appear on the RMX 4000 front panel.
RMX 4000 Front Panel LEDs
Component
Fan Status
Power Module/Rail Status
(AC only)
Fabric Switch Module
(FSM 4000)
Polycom, Inc.
LED ID LED Color
Green
Red
AC Green
Red
DC (OK) Green
DC (FAIL) Red
OFF - all
LED's
ERR Red
RDY Green
ACT Orange
Description
OK.
Warning - Fan or power failure.
OK.
Error - Problem with power supply. When the power
cable is unplugged, the FAIL LED is lit 2-3 seconds
before turning OFF.
OK.
Error - Problem with power supply. When the power
cable is unplugged, the FAIL LED is lit 2-3 seconds
before turning OFF.
In case of a power failure (main/cable/module) all
LED's are OFF.
ON - Major error on card.
Flashes - During card startup.
ON - The card has completed startup successfully.
Flashes - During card startup.
Not in use.
