AND Check Weighing Indicator AD-4404 Instruction Manual page 98

Holding Register (
A word, occupies an address, is 16 bits in length.
A code has these items in a comparison data.
Example for code 0 is as follows:
Comparison data of the code 0
Address Description
1 Name, 1 to 2 characters
2 Name, 3 to 4 characters
3 Name, 5 to 6 characters
4 Name, 7 to 8 characters
5 Name, 9 to 10 characters
6 Name, 11 to 12 characters
7,8 Target value
9,10 Hi
Holding Register (Reference No.=4)
To write comparison data
Address Description
1 to 24 C.D. of the code 0
257 to 280 C.D. of the code 1
513 to 535
C.D. of the code 2
769 to 791
C.D. of the code 3
1025 to 1047
C.D. of the code 4
1281 to 1303
C.D. of the code 5
1537 to 1559
C.D. of the code 6
1793 to 1815
C.D. of the code 7
2049 to 2071
C.D. of the code 8
2305 to 2327
C.D. of the code 9
2561 to 2583
C.D. of the code 10
2817 to 2839
C.D. of the code 11
3073 to 3095
C.D. of the code 12
3329 to 3351
C.D. of the code 13
3585 to 3607
C.D. of the code 14
3841 to 3863
C.D. of the code 15
4097 to 4119
C.D. of the code 16
4353 to 4375
C.D. of the code 17
4609 to 4631
C.D. of the code 18
4865 to 4887
C.D. of the code 19
5121 to 5143
C.D. of the code 20
5377 to 5399
C.D. of the code 21
5633 to 5655
C.D. of the code 22
5889 to 5911
C.D. of the code 23
6145 to 6167
C.D. of the code 24
6401 to 6423
C.D. of the code 25
6657 to 6679
C.D. of the code 26
6913 to 6935
C.D. of the code 27
Reference No.=4. To write words
)
Comparison data of the code 0
Address Description
11, 12 Lo
13, 14 HiHi
15, 16 LoLo
17, 18 Zero band
19, 20 Full
21, 22 Tare mass
23, 24 Target count
Holding Register (Reference No.=4)
To write comparison data
Address
7169 to 7191
7425 to 7447
7681 to 7703
7937 to 7959
8193 to 8215
8449 to 8471
8705 to 8727
8961 to 8983
9217 to 9239
9473 to 9495
9729 to 9751
9985 to 10007
10241 to 10263 C.D. of the code 40
10497 to 10519 C.D. of the code 41
10753 to 10775 C.D. of the code 42
11009 to 11031 C.D. of the code 43
11265 to 11287 C.D. of the code 44
11521 to 11543 C.D. of the code 45
11777 to 11799 C.D. of the code 46
12033 to 12055 C.D. of the code 47
12289 to 12311 C.D. of the code 48
12545 to 12567 C.D. of the code 49
12801 to 12823 C.D. of the code 50
13057 to 13079 C.D. of the code 51
13313 to 13335 C.D. of the code 52
13569 to 13591 C.D. of the code 53
13825 to 13847 C.D. of the code 54
14081 to 14103 C.D. of the code 55
Page 96
Description
C.D. of the code 28
C.D. of the code 29
C.D. of the code 30
C.D. of the code 31
C.D. of the code 32
C.D. of the code 33
C.D. of the code 34
C.D. of the code 35
C.D. of the code 36
C.D. of the code 37
C.D. of the code 38
C.D. of the code 39
AD-4404
