Initial Flow Sequence

7.3.4. 7.3.4. Initial Flow S Initial Flow S
The initial flow sequence is used to prevent the material from scattering before the
batch weighing when a liquid or powder is weighed. When the sequence starts, the
dribble gate is opened first, the medium gate is opened next and the full gate is
opened last. The parameter can be set in each material code.
Concerning Parameters of the Function
Using this sequence to prevent the material from scattering.
Editing these parameters.
Inhibiting comparison during the sequence.
[5q f-35]
[5q f-34]
equence
equence equence
Set the following parameters in each material code.
Initial DF
(Initial dribble flow)
Initial MF
(Initial medium flow)
Edit the parameters in the function mode.
[Function] - [Function setting] - [MatEDIT] - [Edit]
Store the time of the dribble flow comparison inhibit timer.
[Function] - [Function setting] - [Sequence] - [Timer] - [Dribble flow
comparison interrupt timer]
Store the time of the medium flow comparison inhibit timer.
[Function] - [Function setting] - [Sequence] - [Timer] - [Medium flow
comparison interrupt timer]
Page 46 AD-4402
