Customizing the Sub Display

Customizing the Sub Display
7.5.6. 7.5.6. Customizing the Sub Display Customizing the Sub Display
Use the default sub-display pattern, if you want to reset it.
Refer to "10.4. Parameter List" of the function list regarding these items.
Name of
the item
Items to append to sub-display
Row and Colum Address
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
0
1
2
3
Row 0 and 2 are dot matrix display for alphanumerical charactor.
Row 1 and 3 are 7-segment display for numerical charactor.
Items to append to the sub-display
Number Name and Number to Display the Item
0 Not displayed
1 Material
2 Hopper
3 Final value
4 Free fall
5 Preliminary
6 Optional preliminary
7 Over
8 Under
9 Zero Band
10 Full
11 Tare
12 Supplementary flow open timer
13 Supplementary flow close timer
Item index number to be displayed. A maximum
of 32 items of name and number can be set.
At odd: Input the name of the selected item
At even: Input the number concerning the item.
5ub f 1
Sub F1-3 [name]
hopper
19
using alphanumeric characters.
/Row/Col/Dig
0 16 5
Row size
0 to 3
Page 68
Information of
key operation
Resize the item selected.
Columsize Figures
0 to26 1 to12
