AND Multi Function Weighing Indicator AD-4402 Instruction Manual page 115

Category
address
symbol
othf- 2
F1 key function
othf- 3
F2 key function
othf- 4
F3 key function
othf- 5
F4 key function
othf- 6
Parallel I/O Buzzer
AD-4402
Name
0: Not used
1: Display exchange (current weighing / recipe)
2: Manual print
3: Hold
4: Zero clear ( to be zero)
5: Tare clear ( to be zero)
6: Batch start
7: Recipe start
8: Discharge
9: Mixing
10: Pause
11: Internal reseved
12: Restart
13: Forced batch finish
14: Forced recipe finish
15: Forced discharge finish
16: Total command
17: Manual free fall compensation
18: Cancel the last result
19: Error reset
20: Clear the total weight and count for
each material code.
21: Clear the total weight and count for
each recipe code.
22: Clear all total data for material codes.
23: Clear all total data for recipe codes.
24: Clear all total data of material code
and recipe code.
Buzzer output is 2 s. Beep is 0.2 s used
in Contolol I/O, OP-02, OP-05.
Bit 1: Beep (Click sound)
Bit 2: Over
Bit 3: OK
Bit 4: Under
Bit 5: Zero band
Bit 6: Bach finish
Bit 7: Discharge finish
Bit 8: Recipe finish
Bit 9: Mixing finish
Bit 10: Weighing sequence in process
Bit 11: Full (Full filling)
Bit 12: Stable condition
Bit 13: Weighing sequence error
Bit 14: Alarm 1
Bit 15: Alarm 2
Bit 16: Zero error
0: Off (Not used: Open)
1: On (Use: Short or Open)
Descriptions
Page 113
Range
and Default
choices
0 to 24 0
0000000
0000000
10000
00
00000
to
00000
1111111
0
1111111
11
