AND Multi Function Weighing Indicator AD-4402 Instruction Manual page 124

Category address: [Function] - [Function setting] - [Control I/O Function] - [Input]
The list to assign the function for the input terminal of the I/O
No. Function description
0 No function
1 Zero
2 Zero clear
3 Tare
4 Tare clear
5 Batch start
6 Recipe start
7 Discharge start
8 Mixting
External switch control
9 0: Normal bach
1: Loss-in-weigh
10 Manual free fall compensation
11 Total command
12 Cancel the last result
13 Emergency stop
Material / Recipe code,
14
BCD 1
Material / Recipe code,
15
BCD 2
Material / Recipe code,
16
BCD 4
Material / Recipe code,
17
BCD 8
Material / Recipe code,
18
BCD 10
Material / Recipe code,
19
BCD 20
Material / Recipe code,
20
BCD 40
Material / Recipe code,
21
BCD 80
22 Pause
23 Restart
Clear totals of active material
24
code
25 Clear totals of all material code Edge
Read No.
- 26 Clear totals of active recipe
code
Edge 27 Clear totals of all recipe code
Edge 28 Safety check input 1
Edge 29 Safety check input 2
Edge 30 Safety check input 3
Edge 31 Safety check input 4
Edge 32 Safety check input 5
Edge 33 Safety check input 6
Edge 34 Safety check input 7
Level 35 Safety check input 8
Edge 36 Forced batch finish
Edge 37 Forced recipe finish
Edge 38 Forced discharge finish
Level 39 Manual full flow
Level 40 Manual medium flow
Level 41 Manual dribble flow
Level 42 Manual discharge
Level 43 Manual mixing
Level 44 Error reset
Level 45 Hold
Level 46 Key unlock
Level 47 Manual print command
Edge 48 Code recall external switch control
OFF: key, ON: digital switch
Edge 49 Recipe interrupt
Edge 50 Net / gross
Page 122
Function description Read
Edge
Edge
Level
Level
Level
Level
Level
Level
Level
Level
Edge
Edge
Edge
Level
Level
Level
Level
Level
Edge
Level
Level
Edge
Level
Level
Edge
AD-4402
