AND Multi Function Weighing Indicator AD-4402 Instruction Manual page 120

Category
address
symbol
Batch finish output
5q f-21
off
Category address: [Function] - [Function setting] - [Sequence] - [Timer]
Category
address
symbol
Batch monitoring
5q f-31
timer
Batch start delay
5q f-32
timer
Full flow
5q f-33
comparison
interrupt timer
Medium flow
5q f-34
comparison
interrupt timer
Dribble flow
5q f-35
comparison
interrupt timer
Dribble flow
5q f-36
auto-Free Fall
override
5q f-37
Eval delay timer
Discharge start
5q f-38
delay timer
Name
0: Off at next start
(Turning off until next start)
1: Off at over or unstable.
(Turning off when "out of range" or
"unstable condition")
2: Off at zero band.
(Turning off at zero band)
Name
Set the upper limit of the time of
sequence.
If the sequence is not finnished,
sequence error
If 0 is set, the timer does not work.
Set the delay time between start
operation and the flow start
The timer to prevent weighing error due
to vibration of open/close operation.
While the timer is not up, the
comparison does not work.
Set the time until the dribble flow can
start.
Use to prevent compensation error of
automatic free fall compensation or
real time free fall compensation.
Set the time between closing dribble
flow and comparing the result. Refer to
Eval conditions
Set the time between operating
discharge start and opening the
discahrge gate
Descriptions
Descriptions
SQ.ERR4
is displayed.
[5q f-13]
Page 118
Range
and Default
choices
0 to 2 0
Range
and Default
choices
0 to
0 s
65535 s
0.0 to
0.0 s
65535 s
0.0 to
0.0 s
25.5 s
0.0 to
0.0 s
25.5 s
0.0 to
0.0 s
25.5 s
0.0 to
3.0 s
25.5 s
0.1to
0.1 s
25.5 s
0.0 to
0.0 s
25.5 s
AD-4402
