AND Multi Function Weighing Indicator AD-4402 Instruction Manual page 119

Category address: [Function] - [Function setting] - [Sequence] - [Control]
Category
address
symbol
5q f-14
Batch finish actions
Discharge finish
5q f-15
actions
5q f-16
Recipe start actions
Recipe finish
5q f-17
actions
Maximum number
5q f-18
of compensation
Comparison flow
5q f-19
Eval
Free fall
5q f-20
compensation
AD-4402
Name
Select an action at batch finish.
Bit 1: Auto-start mixing
Bit 2: Auto-start discharge
0: No
1: Yes
Select an action at discharge finish.
Bit 1: Auto-clear tare
Bit 2: Start mixing
0: No
1: Yes
Selection of re-zeroing at recipe start.
0: No
1: Yes
Select an action at recipe finish.
Bit 1: Auto-clear tare
Bit 2: Auto-start mixing
Bit 3: Auto-start discharge.
0: No
1: Yes
Set the number of compensation flow.
When 0 is set, there is no flow.
Set the condition with compensation
close timer and stability.
0: Timer is up
Comparison when compensation
close timer is up.
1: Stable and timer is up.
Comparison after stable mark and
compensation close timer is up.
2: Stable or timer is up.
Comparison after stable mark or
compensation close timer is up.
0: No
1: Average of last four free fall times.
2: Real time free fall compensation
Descriptions
(Start mixing automatically)
(Start discharge automatically)
(Not used)
(Use)
(Clear tare automatically)
(Start mixing automatically)
(Not used)
(Use)
(Not used)
(Use)
(Clear tare automatically)
(Start mixing automatically)
(Start discharge automatically)
(Not used)
(Use)
(Not used)
Page 117
Range
and Default
choices
00
to 00
11
00
to 00
11
0 to 1 1
000
to 000
111
0 to
0
255
0 to 2 0
0 to 2 0
